NOVACELL Battery, Green planet, Better Life

Lifepo4 battery 12v 50ah deep cycle lithium ion battery pack

• Model: NV-1250/4S2P
• Dimension: 255*165*220mm
• Nominal voltage: 12.8V
• Charge voltage: 14.65v
• Nominal capacity: 50Ah
• Voltage of single batterycell: Lifepo4 battery cell pouch 3.2V 25Ah., 4S2P
• Dimension: OEM
• Net weight: 6.50KG
• Internal resistance: ≤420mΩ
• End of charge current: 100mA
• End of discharge voltage: 10.0 v
• Charge method: CC/CV
• Max continuous charge current: 10A
• Max continuous discharge current: 50A
• Max pulse discharge current: 100A/10s
• Warranty: 3 years
• Lifecycle: 1500-2000 times at 85% dod, 5000 times at 65% dod, 8000 times at 40% dod.
• BMS protection: over-charge,over-discharge,over-current,short circuit
• Charge temperature :0~45℃
• Discharge temperature: -10~55℃

Advantages

Lithium Iron Phosphate (LiFePO4) Battery

Safest lithium chemistry with high energy density

Built-in automatic protection for over-charge,over discharge,over current and over temperature

Efficient & long-lasting up to 7000+ cycles

>2000 cycles @0.2C,Charge/Discharge at 100% DOD,end of life 70% capacity

Internal cell balancing

Wide temperature range:-20℃~60℃

Maintenance free

Light weight,about 40%~50% of the weight of a comparable SLA battery

Replacement for SLA battery with compatible Housing

Application

Large electric vehicles: buses, electric cars, tourist routes and hybrid cars

Light electric vehicles: electric bicycles, golf carts, small flatbed battery cars, forklifts, clean cars, electric wheelchairs, etc .

Power tools: electric drill, electric saw, lawn mower, etc

Toys:Remote control cars, boats, aircraft ,etc.

Solar energy and wind power storage equipment

UPS, emergency lights, warning lights and miner's lamp

Small medical equipment and portable equipment.
